440167

(3-Glycidyloxypropyl)trimethoxysilane

≥98%

Synonym(s):

3-(2,3-Epoxypropoxy)propyltrimethoxysilane, GLYMO, Glycidyl 3-(trimethoxysilyl)propyl ether

Sign In to View Organizational & Contract Pricing.

Select a Size

About This Item

Empirical Formula (Hill Notation):
C9H20O5Si
CAS Number:
2530-83-8
Molecular Weight:
236.34
UNSPSC Code:
12352103
NACRES:
NA.23
PubChem Substance ID:
24867573
EC Number:
219-784-2
Beilstein/REAXYS Number:
4308125
MDL number:
MFCD00005144

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Product Name

(3-Glycidyloxypropyl)trimethoxysilane, ≥98%

InChI key

BPSIOYPQMFLKFR-UHFFFAOYSA-N

InChI

1S/C9H20O5Si/c1-10-15(11-2,12-3)6-4-5-13-7-9-8-14-9/h9H,4-8H2,1-3H3

SMILES string

CO[Si](CCCOCC1CO1)(OC)OC

assay

≥98%

form

liquid

refractive index

n20/D 1.429 (lit.)

bp

120 °C/2 mmHg (lit.)

density

1.07 g/mL at 25 °C (lit.)

Quality Level

200

Looking for similar products? Visit Product Comparison Guide

Related Categories

Application

GPTMS is widely used as a silica precursor. GPTMS alone with tetraethylortosilicate (TEOS) can be blended with chitosan for use as a filler for polymeric scaffold for bone tissue engineering. It can also be coated on the surface of aluminium alloy to protect from corrosion. GPTMS can used to functionalize (wrap) multi-walled carbon nanotubes (MWCNTs) which can be used as s a reinforcement in epoxy matrix nanocomposites.
Pre-treatment of carbon steel with 3-(Glycidoxypropyl)trimethoxysilane enhances the dry and wet adhesion while reducing the cathotic disbondment rate of an epoxy coating

General description

(3-Glycidyloxypropyl)trimethoxysilane (GPTMS) is a bifunctional organosilane with three methoxy groups on one side and an epoxy ring on the other. The methoxy groups bind well with glass substrates creating a 3D matrix. The epoxy group is reactive with amides, alcohols, thiols and acids. GPTMS is highly reactive in water and can be used as a linking agent between the surface of the silica and the polymeric matrix.

pictograms

Corrosion
GHS05

signalword

Danger

hcodes

H318,H412

Hazard Classifications

Aquatic Chronic 3 - Eye Dam. 1

Storage Class

10 - Combustible liquids

wgk

WGK 1

flash_point_f

235.4 °F - closed cup

flash_point_c

113 °C - closed cup

ppe

Eyeshields, Gloves, multi-purpose combination respirator cartridge (US)

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
SDBB1794
SDBB1793
SDBB0475
STBL0642
STBL2731

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

  1. Which document(s) contains shelf-life or expiration date information for a given product?

    If available for a given product, the recommended re-test date or the expiration date can be found on the Certificate of Analysis.

  2. How do I get lot-specific information or a Certificate of Analysis?

    The lot specific COA document can be found by entering the lot number above under the "Documents" section.

  3. Is Product 440167 (3-Glycidyloxypropyl)trimethoxysilane GLYMO, equivalent to Dow's Z-6040?

    Yes. This listing is manufactured by Dow Corning Corporation and distributed by Sigma-Aldrich.

  4. What can Product 440167, 3-Glycidyloxypropyl)trimethoxysilane GLYMO, be used for?

    According to Dow Corning®, 3-GLYCIDOXYPROPYLTRIMETHOXYSILANE can be used as a coupling agent for many thermoset resins with glass or  mineral fillers. Specifically, it has been used as a reinforcement treatment on glass fiber to improve physical properties (especially wet strength) or as  an adhesion promoter to improve the bonding of a polymer coating or adhesive to glass, metals or other polymeric surfaces.

  5. What is the viscosity of Product 440167 (3-Glycidyloxypropyl)trimethoxysilane GLYMO?

    This material is a low viscosity liquid with an average value of about 3 centistokes. Please note that this value is not part of our specifications.

  6. Where can I find more detailed information about how to use Product 440167. 3-Glycidyloxypropyl)trimethoxysilane, GLYMO, in adhesion/reinforcement applications?

    Dow Corning® has published a technical bulletin on this product, which is available by calling Technical Service at 800-231-8327.

  7. How do I find price and availability?

    There are several ways to find pricing and availability for our products. Once you log onto our website, you will find the price and availability displayed on the product detail page. You can contact any of our Customer Sales and Service offices to receive a quote.  USA customers:  1-800-325-3010 or view local office numbers.

  8. What is the Department of Transportation shipping information for this product?

    Transportation information can be found in Section 14 of the product's (M)SDS.To access the shipping information for this material, use the link on the product detail page for the product.

  9. My question is not addressed here, how can I contact Technical Service for assistance?

    Ask a Scientist here.

Jadra Mosa et al.
Membranes, 9(9) (2019-08-30)
Organic/inorganic hybrid membranes that are based on GTT (GPTMS-TMES-TPTE) system while using 3-Glycidoxypropyl-trimethoxysilane (GPTMS), Trimethyletoxisilane (TMES), and Trimethylolpropane triglycidyl ether (TPTE) as precursors have been obtained while using a combination of organic polymerization and sol-gel synthesis to be used as
Functionalization of carbon nanotubes with (3-glycidyloxypropyl)-trimethoxysilane: Effect of wrapping on epoxy matrix nanocomposites.
Hoepfner, et al.
Journal of Applied Polymer Science, 133(47), 814-820 (2016)
Ahmed A Nada et al.
International journal of biological macromolecules, 133, 538-544 (2019-04-22)
Homogenous allocation of inorganic particles in a polymeric matrix is a challenge. In this work, we discuss electrospinning of chitosan /gelatin using CS-Si (chitosan silicone hybrids) as well as the formation of homogeneously distributed Zn elements inside chitosan nanofiber through
Room temperature ionic liquids for epoxy nanocomposite synthesis: Direct dispersion and cure.
Throckmorton JA, et al.
Composites Science and Technology, 86(47), 38-44 (2013)
Journal of Organometallic Chemistry, 625, 208-208 (2001)
