E1510

Sigma-Aldrich

Ethidium bromide solution

BioReagent, for molecular biology, 10 mg/mL in H2O

Synonym(s):

3,8-Diamino-5-ethyl-6-phenylphenanthridinium bromide, EtBr, Homidium bromide

Sign Into View Organizational & Contract Pricing
All Photos(2)

About This Item

Empirical Formula (Hill Notation):
C21H20BrN3
CAS Number:
1239-45-8
Molecular Weight:
394.31
Beilstein:
3642536
MDL number:
MFCD00011724
UNSPSC Code:
41105322
PubChem Substance ID:
24894418
NACRES:
NA.31

grade

for molecular biology

Quality Level

200

product line

BioReagent

concentration

10 mg/mL in H2O

technique(s)

electrophoresis: suitable

suitability

suitable for gel electrophoresis

SMILES string

[Br-].CC[n+]1c(-c2ccccc2)c3cc(N)ccc3c4ccc(N)cc14

InChI

1S/C21H19N3.BrH/c1-2-24-20-13-16(23)9-11-18(20)17-10-8-15(22)12-19(17)21(24)14-6-4-3-5-7-14;/h3-13,23H,2,22H2,1H3;1H

InChI key

ZMMJGEGLRURXTF-UHFFFAOYSA-N

Looking for similar products? Visit Product Comparison Guide

Application

Ethidium bromide solution has been used:
  • as a stain to visualize U937 cells to assess cell viability
  • to detect polymerase chain reaction products
  • in agarose gel electrophoresis based gel retardation assay

Ethidium bromide (EtBr) is the most commonly used nucleic acid stain for PAGE or agarose gel electrophoresis. The fluorescence of EtBr increases 21-fold upon binding to double-stranded RNA and 25-fold on binding double-stranded DNA so that destaining the background is not necessary with a low stain concentration (10 μg/ml). Ethidium bromide has been used in a number of fluorimetric assays for nucleic acids. It has been shown to bind to single-stranded DNA (although not as strongly) and triple-stranded DNA. Because of its ability to bind to DNA, EtBr is an inhibitor of DNA polymerase.

Biochem/physiol Actions

Ethidium bromide intercalates double-stranded DNA and RNA and acts as a frameshift mutagen. It can also be used in conjunction with acridine orange to differentiate between viable, apoptotic and necrotic cells.

Reconstitution

For staining a gel after electrophoresis, dilute a sample of the stock solution to 0.5 μg/ml with water and incubate the gel for 15-30 min. Destaining is usually not needed but can be carried out in water for 15 min if decreased background is necessary. The DNA bands can then be detected on a UV light box (254 nm wavelength). Ethidium bromide can also be incorporated into the gel and running buffer at 0.5 μg/ml and visualized immediately after electrophoresis.

Other Notes

2024 CiteAb Award Winner for Supplier Succeeding in Parkinson′s Research

related product

Product No.
Description
Pricing

Pictograms

Skull and crossbonesHealth hazard
GHS06,GHS08

Signal Word

Danger

Hazard Statements

H331,H341

Hazard Classifications

Acute Tox. 3 Inhalation - Muta. 2

WGK

nwg

Flash Point(F)

Not applicable

Flash Point(C)

Not applicable

Certificates of Analysis (COA)

Search for Certificates of Analysis (COA) by entering the products Lot/Batch Number. Lot and Batch Numbers can be found on a product’s label following the words ‘Lot’ or ‘Batch’.

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

pH-sensitive oncolytic adenovirus hybrid targeting acidic tumor microenvironment and angiogenesis
Choi JW, et al.
Journal of Controlled Release : Official Journal of the Controlled Release Society, 205, 134-143 (2015)
Application of a new wall-less plate technology to complex multistep cell-based investigations using suspension cells
Quinones GA, et al.
Blood, 121(7), e25-e33 (2013)
Keith E Herold et al.
Methods in molecular biology (Clifton, N.J.), 504, 441-458 (2009-01-23)
A prototype handheld, compact, rapid thermocycler was developed for multiplex analysis of nucleic acids in an inexpensive, portable configuration. Instead of the commonly used Peltier heating/cooling element, electric thin-film resistive heater and a miniature fan enable rapid heating and cooling
Ulrich Braunschweig et al.
Genome research, 24(11), 1774-1786 (2014-09-27)
Alternative splicing (AS) of precursor RNAs is responsible for greatly expanding the regulatory and functional capacity of eukaryotic genomes. Of the different classes of AS, intron retention (IR) is the least well understood. In plants and unicellular eukaryotes, IR is
Suguru Shigemori et al.
Microbial cell factories, 14, 189-189 (2015-11-27)
Mucosal delivery of therapeutic proteins using genetically modified strains of lactic acid bacteria (gmLAB) is being investigated as a new therapeutic strategy. We developed a strain of gmLAB, Lactococcus lactis NZ9000 (NZ-HO), which secretes the anti-inflammatory molecule recombinant mouse heme
View All Related Papers

Protocols

Recombinant eSpCas9 Protein for RNP-Based Genome Editing

The CRISPR (Clustered Regularly Interspaced Short Palindromic Repeats) system was discovered in bacteria, where it functions as an adaptive immune system against invading viral and plasmid DNA.

GenElute™ Blood Genomic DNA Kit Protocol

The GenElute™ Blood Genomic DNA Kit Protocol provides a simple and convenient way to isolate pure genomic DNA from fresh or aged whole blood.

GenElute™ Mammalian Genomic DNA Miniprep Kit Protocol

The GenElute Mammalian Genomic DNA Purification Kit Protocol describes the isolation of pure, high molecular weight DNA from a variety of mammalian sources.

GenElute™ Bacterial Genomic DNA Kit Protocol (NA2100, NA2110, NA2120)

GenElute™ Bacterial Genomic DNA Kit protocol describes a simple and convenient way for the isolation of pure genomic DNA from bacteria.

Related Content

Ethidium Bromide

Ethidium bromide is a well-known and widely used fluorescent dye in biotechnology research.

Our team of scientists has experience in all areas of research including Life Science, Material Science, Chemical Synthesis, Chromatography, Analytical and many others.

Contact Technical Service
