341088

Sigma-Aldrich

1,9-Dimethyl-Methylene Blue zinc chloride double salt

Dye content 80 %

Synonym(s):

DMMB, Taylor’s Blue

Sign Into View Organizational & Contract Pricing
All Photos(2)

About This Item

Empirical Formula (Hill Notation):
C18H22ClN3S · 0.5ZnCl2
CAS Number:
931418-92-7
Molecular Weight:
416.05
MDL number:
MFCD19686959
UNSPSC Code:
12171500
PubChem Substance ID:
24860900
NACRES:
NA.47

form

powder

Quality Level

200

composition

Dye content, 80%

impurities

<20% water

mp

250 °C (dec.) (lit.)

λmax

649 nm

ε (extinction coefficient)

≥10000 at 243-249 nm in H2O
≥18000 at 285-291 nm in H2O
≥25000 at 594-600 nm in H2O
≥35000 at 646-652 nm in H2O

application(s)

diagnostic assay manufacturing
hematology
histology

storage temp.

room temp

SMILES string

[Cl-].[Cl-].Cl[Zn]Cl.CN(C)c1cc(C)c2N=C3C(C)=C\C(C=C3Sc2c1)=[N+](/C)C.CN(C)c4cc(C)c5N=C6C(C)=C\C(C=C6Sc5c4)=[N+](/C)C

InChI

1S/2C18H22N3S.4ClH.Zn/c2*1-11-7-13(20(3)4)9-15-17(11)19-18-12(2)8-14(21(5)6)10-16(18)22-15;;;;;/h2*7-10H,1-6H3;4*1H;/q2*+1;;;;;+2/p-4

InChI key

MKLBAKXCEQNMBC-UHFFFAOYSA-J

Related Categories

Application

1,9-Dimethyl-Methylene Blue zinc chloride double salt has been used for the quantification of sulfated glycosaminoglycans.
DMMB is a cationic dye that specifically binds to sulfated glycosaminoglycans (sGAG) with an absorbance at ~525 nm. It has been used to quantitate glycosaminoglyans such as chondroitin sulfate, keratin sulfate, and heparan sulfate and sGAG chains in proteoglycans. One limitation to this method The sGAG-DMMB complex is unstable in solution and may precipitate. Precipitation of the complex was shown to improve stability.

Pictograms

Exclamation mark
GHS07

Signal Word

Warning

Hazard Statements

H319

Precautionary Statements

P305 + P351 + P338

Hazard Classifications

Eye Irrit. 2

WGK

WGK 3

Personal Protective Equipment

dust mask type N95 (US), Eyeshields, Gloves
