634646

Sigma-Aldrich

Magnesium oxide

(single crystal substrate), ≥99.9% trace metals basis, <100>, L × W × thickness 10 mm × 10 mm × 0.5 mm

Sign Into View Organizational & Contract Pricing
All Photos(1)

About This Item

Linear Formula:
MgO
CAS Number:
1309-48-4
Molecular Weight:
40.30
EC Number:
215-171-9
MDL number:
MFCD00011109
UNSPSC Code:
12352303
PubChem Substance ID:
24882639
NACRES:
NA.23

description

single side polished

Quality Level

100

Assay

≥99.9% trace metals basis

form

(single crystal substrate)

dielectric constant

9.8

reaction suitability

reagent type: catalyst
core: magnesium

L × W × thickness

10 mm × 10 mm × 0.5 mm

transmittance

200-400 nm, 90%
500-1000 nm, 98%

mp

2852 °C (lit.)

semiconductor properties

<100>

SMILES string

O=[Mg]

InChI

1S/Mg.O

InChI key

CPLXHLVBOLITMK-UHFFFAOYSA-N

Looking for similar products? Visit Product Comparison Guide

Related Categories

Features and Benefits

Magnesium oxide is an excellent single-crystal substrate for thin films of ferromagnetic, photo-electronic, and high Tc superconductor materials.

Physical properties

Thermal expansion: 12.8 x 10-6/°C

Physical form

cubic (a = 4.216 Å)

Storage Class Code

11 - Combustible Solids

WGK

WGK 1

Flash Point(F)

Not applicable

Flash Point(C)

Not applicable

Personal Protective Equipment

dust mask type N95 (US), Eyeshields, Gloves
