435171

Sigma-Aldrich

Diethoxy(3-glycidyloxypropyl)methylsilane

97%

Sign Into View Organizational & Contract Pricing
All Photos(1)
Synonym(s):
(3-Glycidyloxypropyl)methyldiethoxysilane, [3-(2,3-Epoxypropoxy)propyl]methyldiethoxysilane
Empirical Formula (Hill Notation):
C11H24O4Si
CAS Number:
2897-60-1
Molecular Weight:
248.39
Beilstein:
121965
EC Number:
220-780-8
MDL number:
MFCD00046995
UNSPSC Code:
12352103
PubChem Substance ID:
24867224
NACRES:
NA.23

Quality Level

100

Assay

97%

form

liquid

refractive index

n20/D 1.431 (lit.)

bp

122-126 °C/5 mmHg (lit.)

density

0.978 g/mL at 25 °C (lit.)

SMILES string

CCO[Si](C)(CCCOCC1CO1)OCC

InChI

1S/C11H24O4Si/c1-4-14-16(3,15-5-2)8-6-7-12-9-11-10-13-11/h11H,4-10H2,1-3H3

InChI key

OTARVPUIYXHRRB-UHFFFAOYSA-N

Looking for similar products? Visit Product Comparison Guide

Related Categories

General description

Diethoxy(3-glycidyloxypropyl)methylsilane (GPMS) is an epoxysilane which can be used as a silane coupling agent for the surface treatment of a variety of materials. These silanes can also be used as adhesion promoters by modifying the surface properties of the substrates and elastomeric materials.

Application

Coverslips coated with diethoxy(3-glycidyloxypropyl)methyl silane were used as sample holders for electrostatically holding particles for optical microscopy.{52} It may be used to introduce epoxy groups to Fe3O4SiO2 nanoparticles. {53} Self assembled monolayer (SAMs) of diethoxy(3- glycidyloxypropyl)methylsilane could be formed on the oxide layer of silicon wafer to render them siloxane functionalities.{54}
GPMS can be used in the surface modification of a variety of particles such as cellulose nanocrystals, silica nanomaterials and other silicon based substrates. It functionalizes these surfaces by attaching the epoxy-silane groups with the surface molecules.

Pictograms

Exclamation mark
GHS07

Signal Word

Warning

Hazard Statements

H315,H319,H335

Hazard Classifications

Eye Irrit. 2 - Skin Irrit. 2 - STOT SE 3

Target Organs

Respiratory system

WGK

WGK 3

Flash Point(F)

251.6 °F

Flash Point(C)

122 °C

Personal Protective Equipment

dust mask type N95 (US), Eyeshields, Gloves

Certificates of Analysis (COA)

Search for Certificates of Analysis (COA) by entering the products Lot/Batch Number. Lot and Batch Numbers can be found on a product’s label following the words ‘Lot’ or ‘Batch’.

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Colloidal Particles that Rapidly Change Shape via Elastic Instabilities.
Epstein E, et al.
Small, 11(45), 6051-6057 (2015)
Surface-modified cellulose nanocrystals for biobased epoxy nanocomposites
Yue L, et al.
Polymer, 134(45), 155-162 (2018)
Zwitterionic SiO 2 nanoparticles as novel additives to improve the antifouling properties of PVDF membranes
Zhu J, et al.
Royal Society of Chemistry Advances, 5(66), 53653-53659 (2015)
Photoconjugation of molecularly imprinted polymer with magnetic nanoparticles.
Xu C, et al.
ACS Applied Materials & Interfaces, 5(11), 5208-5213 (2013)
Influence of nanoparticle surface treatment on the electrical properties of cycloaliphatic epoxy nanocomposites
Huang X, et al.
IEEE Transactions on Dielectrics and Electrical Insulation, 17(2), 635-643 (2010)
